Product code: CMC-50012 Categories: Customize Your Vessel, Maintain or improve your engine, Outboard Jack Plates, Outboard Tilt and Trim$205.00
The CMC Static Jack Plate 5 inch vertical outboard motor extension allows the motor to be mounted 5 inches higher than the
standard mounting height on the transom.
It is a must for easy conversion from prop drive to jet drive.
Another application includes mounting the 5 inch vertical extension on a hydraulic jack plate to raise the motor higher on shallow running boats that are equipped with tunnel extensions.
Constructed of Extruded 6061-T6 Aluminum alloy. (#50012) They are 5” wide and 20-1/2” long. It is rated for 300 HP and smaller motors.
Our offers
Quick View
High Speed Hydraulic Power Lift – 10 inch setback without gauge
High_Speed Power-Lift: 10 inch setback without gauge
Quick View
CMC Hydraulic Jack Plate
This dependable, self contained, and water proof CMC Hydraulic Jack Plate from Boaters Catalog has a maximum lifting capacity of 7,853 pounds of thrust. You will have no problem lifting even a V-6 300 hp max. motor at full throttle. The hydraulic actuator is mounted inside the structure of the Power-Lift, yet it is fully accessible without removing the engine. There are no hoses to contain, nor will you have to contend with mounting a pump and reservoir inside your boat, as is the need with other transom jacks.
The catalog cannot determine freight accurately. We will contact you after the sale with the correct freight. If you wish, you may call us at 800-745-0765 for a freight quote prior to ordering.
Price range: $1,179.00 through $1,601.00
Select options
This product has multiple variants. The options may be chosen on the product page
Description
Features
Description
The CMC Static Jack Plate 5 inch vertical outboard motor extension allows the motor to be mounted 5 inches higher than the standard mounting height on the transom. This vertical motor extension is a must for converting from jet drive to outboard. If you boat in shallow waters only this unit can save your skeg and prop from damage by raising it higher than normal mounting height.
LIMITED WARRANTY
CMC Marine, Inc. warrants to the first retail purchaser of its products that CMC Marine, Inc. will replace or repair the product, at its sole discretion, if any defects in material or workmanship are reported within the applicable warranty periods set out below from the date of the first retail purchase, subject to the remedies, exclusions, and limitations in this Limited Warranty. This limited warranty is effective for all CMC Marine, Inc. products purchased after January 1, 2007.
1. CMC hydraulic jack plates, CMC Tilt & Trim units: Hydraulic Actuator mechanism – 1 year
2. CMC hydraulic jack plates, manual jack plates and CMC Tilt & Trim units: frame structure assembly – 5 years
3. All other CMC Marine, Inc. Products: 1 year
See all our other quality CMC outboard engine products here.
-Designed to offer exceptional performance and reliability
-Made using high-quality materials for long-lasting service life
-Proven to live up to the most demanding marine conditions
-Engineered to meet or exceed the highest quality standards
Since 1956, CMC® has produced products for marine, oilfield, industrial computer, and industrial hydraulic markets. CMC has led the marine market with jack plates for over 30 years and with aftermarket tilt and trim units for over 20 years. Now all hydraulic units are driven with patented hydraulic actuator. CMC was the originator and pioneer of providing a self-contained hydraulic jack plate. CMC utilizes the finest computerized machinery available for precision and speed. This enables to manufacture top quality products at a very competitive price, giving the consumer many years of trouble free service at the best price. Testing procedures are implemented on each item to meet certain parameters before any unit is packaged for shipment. This quality control is done to ensure that CMC maintains the lowest service-repair record possible.
